How to Turn Your Paper Into a One-Page Infographic

You have a figure that took months to get right, a results table with twelve rows, and a request from your department for "something visual" about the paper by Friday. The temptation is to paste the figure onto a coloured background, add the abstract, and call it an infographic.

A one-page infographic is not a shrunken paper. It is a single result, made visible enough that someone who never opens the PDF still leaves with it. Here is how to get there.

Choose the One Result

Everything on the page serves one result. Pick it before you open any design tool.

Ask: if a reader remembers one sentence from this paper, which one should it be? Write it as a headline in plain words, with the number if there is one. "Afternoon walks helped students fall asleep about ten minutes faster" works. "Effects of moderate physical activity on sleep onset latency" does not.

Then write the four supporting lines:

1. The question in one sentence.
2. What you did in one sentence, no technique names.
3. What it means for the reader you have in mind.
4. One honest limit (one sample, one setting, one model).

If you cannot pick one result, you probably have two infographics, not one crowded one.

Four Layout Patterns

Most good research infographics use one of these four shapes. Pick the one that matches your result, not the one that looks busiest.

Pattern	Best for	Shape on the page	Watch out for
Single big number	A clear effect size, rate or count	Headline number at the top, one simple chart, three short lines below	Stripping away the uncertainty or the comparison group
Before and after	An intervention, policy or treatment	Two columns side by side with the same scale	Implying causation the design does not support
Process flow	A method, pipeline or pathway	Three to five steps left to right or top to bottom	Too many steps; group them
Comparison grid	Several conditions, groups or models	A small table or set of icons with a highlighted winner	Hiding the cases where the winner did not win

All four share the same frame: headline result at the top, the visual in the middle, meaning and limit underneath, and the title, authors, journal and DOI or link at the bottom.

A Worked Example

Say you have a machine learning paper showing that a smaller model, trained on carefully cleaned data, matched a much larger model on a medical image task. The numbers below are invented for illustration.

• Pattern: comparison grid.
• Headline: "A model one tenth the size matched the big one, once the training labels were cleaned."
• Visual: two bars per model (original labels, cleaned labels), same axis, labelled directly with their scores.
• What we did: "We fixed labelling errors in a public dataset, then retrained models of different sizes."
• What it means: "Teams with small compute budgets may get more from cleaning data than from scaling up."
• Limit: "One dataset, one task."
• Footer: title, authors, venue, link to the paper and code.

The original paper might have six tables. The infographic has one chart and five sentences, and that is the point.

Reusing Your Own Figures

Your figures may not be yours to reuse freely. Check before you redraw.

If the paper is open access under a CC BY 4.0 license, anyone, including you, may adapt the material for any purpose, as long as they give appropriate credit, link to the license and indicate if changes were made. PLOS, for example, says at the time of writing (October 2026) that all its journals publish under a CC BY license and that authors retain copyright.

Subscription articles are different. Elsevier's copyright page says that when you publish under the subscription model you typically transfer copyright to the publisher, though authors keep the right to reuse their own figures, tables and images from the article in their own new works. It also says that for subscription articles its list of allowed uses is exhaustive, and anything beyond it needs permission. Other publishers have their own terms, so read your publishing agreement, and if in doubt, ask.

Third-party images inside your figures (a stock photo, a map, a diagram you adapted from another paper) carry their own licenses. Redrawing your own data as a new, simpler chart is often the cleanest route, and it usually reads better on one page anyway. Still credit the paper as the source of the data.

Print and Screen Versions

Make two files, not one.

Print

The print version can be a full page in portrait. Keep the text large enough to read at arm's length, keep important elements away from the edges, and ask whoever is printing it (your department, the conference, a print shop) for their required file format, resolution and margins before you export.

Screen

A tall page does not survive social feeds. At the time of writing (October 2026), LinkedIn's photo sharing help says photo aspect ratios can range from 3:1 to 4:5 (width to height), that an image with a larger ratio is centered and cropped to fit, that uploads are limited to 5 MB, and that it recommends images 1080 pixels wide. So make a 4:5 screen version with just the headline, the chart and the footer, and let the post text carry the rest. Our LinkedIn post templates show how to write that text.

Make It Accessible

An infographic that some readers cannot read is a smaller audience by design. WebAIM's guide to WCAG contrast and color sets out the rules worth following:

• Text contrast. WCAG 2's Level AA criterion asks for a contrast ratio of at least 4.5:1 between text and its background, or 3:1 for large text (18 point and larger, or 14 point and bold).
• Chart contrast. Parts of a graphic that people need in order to understand it should have at least 3:1 contrast against adjacent colors.
• Not color alone. Color should not be the only way information is conveyed. Label lines and bars directly instead of relying on a red and green legend.

Then write alt text that states the finding, not the design ("Bar chart: the small model matched the large one after cleaning"). LinkedIn's photo sharing help says you can add alternative text to images you upload for members using screen readers. Where you post the infographic on a web page, put the text version underneath it too.

Where Amplify Fits

If you do not have a designer, or a free afternoon, Amplify makes a one-page, print-ready infographic from your paper, as one of four formats in a single order alongside a video abstract of about 3 minutes, a 45 to 60 second vertical short and an audio brief.

It is generated from the PDF you upload and nothing else, so it does not pull in claims from the open web, and it carries the title, the authors and a link back to the paper of record. It arrives as three variants you can edit line by line, so you can sharpen the headline yourself. A person reviews every format before it is released, and nothing publishes until you approve it. If you also need a graphical abstract for a journal, check that journal's specifications and AI policy, and ask the editor if you are unsure.

One Page, One Result

A good research infographic is a decision more than a design: one result, one shape, one honest limit. Make it once, export a print and a screen version, and it will work on a poster board, in a slide deck and on a feed. For journal graphical abstracts specifically, our comparison of graphical abstract tools covers the options.
